ABB ACS800 Series - How to view and reset the fault history

Control panel
14
How to display the full name of the actual signals
How to view and reset the fault history
Note: The fault history cannot be reset if there are active faults or warnings.
Step Action Press Key Display
1. To display the full name of the three
actual signals.
Hold 1 L -> 1242.0 rpm I
F
REQUENCY
CURRENT
POWER
2. To return to the Actual Signal Display
Mode.
Release 1 L -> 1242.0 rpm I
FREQ 45.00 Hz
CURRENT 80.00 A
POWER 75.00 %
Step Action Press Key Display
1. To enter the Actual Signal Display
Mode.
1 L -> 1242.0 rpm I
F
REQ 45.00 Hz
CURRENT 80.00 A
POWER 75.00 %
2. To enter the Fault History Display. 1 L -> 1242.0 rpm I
1 LAST FAULT
+OVERCURRENT
6451 H 21 MIN 23 S
3. To select the previous (UP) or the next
fault/warning (DOWN).
1 L -> 1242.0 rpm I
2 LAST FAULT
+OVERVOLTAGE
1121 H 1 MIN 23 S
To clear the Fault History. 1 L -> 1242.0 rpm I
2 LAST FAULT
H MIN S
4. To return to the Actual Signal Display
Mode.
1 L -> 1242.0 rpm I
F
REQ 45.00 Hz
CURRENT 80.00 A
POWER 75.00 %
ACT
ACT
ACT
RESET
