274 Additional parameter data
15.10 AO2 out min REAL 16 0 … 22.7 mA 4.000 mA
15.11 AO2 src max REAL 32 -32768…32768 - 100.000
15.12 AO2 src min REAL 32 -32768…32768 - -100.000
15.13 AO3 src Val pointer 32 - - Frequency
15.14 AO3 filt time REAL 16 0…30 s 0.100 s
15.15 AO3 out max REAL 16 0 … 22.7 mA 22.000 mA
15.16 AO3 out min REAL 16 0 … 22.7 mA 4.000 mA
15.17 AO3 src max REAL 32 -32768…32768 - 50.000
15.18 AO3 src min REAL 32 -32768…32768 - 0.000
15.19 AO4 src Val pointer 32 - - Frequency
15.20 AO4 filt time REAL 16 0…30 s 0.100 s
15.21 AO4 out max REAL 16 0 … 22.7 mA 22.000 mA
15.22 AO4 out min REAL 16 0 … 22.7 mA 4.000 mA
15.23 AO4 src max REAL 32 -32768…32768 - 50.000
15.24 AO4 src min REAL 32 -32768…32768 - 0.000
15.25 AO ctrl word UINT32 32 0b0000…0b1111 - 0b0000
16 System
16.01 Local lock Bit pointer 32 - - C.FALSE
16.02 Parameter lock enum 16 0…2 - Open
16.03 Pass code INT32 32 0…2147483647 - 0
16.04 Param restore enum 16 0…2 - Done
16.07 Param save enum 16 0…1 - Done
16.09 User set sel enum 32 1…10 - No request
16.10 User set log Pb 32 0…1024 - N/A
16.11 User IO sel lo Bit pointer 32 - - C.FALSE
16.12 User IO sel hi Bit pointer 32 - - C.FALSE
16.14 Reset ChgParLog enum 16 0…1 - Done
16.15 Menu set sel enum 16 0…2 - No request
16.16 Menu set active enum 16 0…2 - Short menu
16.17 Power unit enum 16 0…1 - kW
19 Speed calculation
19.01 Speed scaling REAL 16 0…30000 rpm 1500 rpm
19.02 Speed fb sel enum 16 0…2 - Estimated
19.03 MotorSpeed filt REAL 32 0…10000 ms 8.000 ms
19.06 Zero speed limit REAL 32 0…30000 rpm 30.00 rpm
19.07 Zero speed delay UINT32 16 0…30000 ms 0 ms
19.08 Above speed lim REAL 16 0…30000 rpm 0 rpm
19.09 Speed TripMargin REAL 32 0…10000 rpm 500.0 rpm
19.10 Speed window REAL 16 0…30000 rpm 100 rpm
19.13 Speed fbk fault enum 16 0…2 - Fault
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
