NoteArticle numberSpare part
Used with protection type Clean
Room.
Used for robots with food grade
lubrication.
Used with protection type Hy-
gienic.
Replace if damaged.
3HAC059703-001Housing extender unit, Clean
Room
Housing extender unit, food
grade lubrication
Housing extender unit, Hygienic
Not used with protection class
IP40.
Replace if damaged.
3HAC056724-001 /
3HAC080702-001
Gasket on cable housing cover
Replace if damaged.3HAC044660-001PTFE film on cable housing
cover
Replace if damaged3HAC044869-001Washer
Replace if damaged.3HAC059684-001Housing small cover
Used with protection type Clean
Room.
Used for robots with food grade
lubrication.
Used with protection type Hy-
gienic.
Replace if damaged.
3HAC056142-001Housing small cover, Clean
Room
Housing small cover, food grade
lubrication
Housing small cover, Hygienic
Not used with protection class
IP40.
Replace if damaged.
3HAC058822-001 /
3HAC080709-001
Gasket for tubular cover
Not used with protection class
IP40.
Replace if damaged.
3HAC056707-001 /
3HAC080701-001
Gasket for tubular cable housing
cover
Required tools and equipment
NoteArticle numberEquipment, etc.
Used to refit the radial sealing, if re-
placement is needed.
3HAC049699-001Axis-4 sealing assembly tool
set
Used to release the motor brakes.-24 VDC power supply
Content is defined in section Standard
toolkit on page 890.
-Standard toolkit
Required consumables
NoteArt. no.Consumable
Loctite 7063-Cleaning agent
Loctite 57412340011-116Flange sealing
For robots with protection class
IP67
For robots with protection type
Foundry Plus
Loctite 2433HAB7116-1Locking liquid
Continues on next page
246 Product manual - IRB 1200
3HAC046983-001 Revision: S
© Copyright 2014 - 2021 ABB. All rights reserved.
4 Repair
4.3.2 Replacing the axis-4 FPC unit, housing extender unit and housing extender sealings
Continued
