2.2.2 Protection covers
Protection covers for water and dust proofing
For robots delivered with option 803-2 Ethernet, Parallel, Air (IRC5)
For robot delivered with option 3303-2 Ethernet, Parallel, Air (OmniCore)
A dust cap and two protectors are delivered together with the robot and must be
well fitted to the connectors in any application requiring water and dust proofing.
NoteArt. no.Equipment
Used to cover unused connectors for
water and dust proofing. Replace if
damaged.
3HEA800897-002Dust cap
Used with option 803-2 (IRC5) or option
3303-2 (OmniCore).
3HAC047543-001M12 protector
Used to cover unused connectors for
water and dust proofing. Replace if
damaged.
Used with option 803-2 (IRC5) or option
3303-2 (OmniCore).
3HAC047539-001RJ 45 protector
Used to cover unused connectors for
water and dust proofing. Replace if
damaged.
Protection covers for Foundry Plus robots
For robots with protection type Foundry Plus
Extra protection covers, sealing and plugs are delivered together with Foundry
Plus robots and must be fitted to the robot during installation.
NoteArt. no.Equipment
Used with protection type Foundry Plus.3HAC058350-001Protection bracket for
CP/CS connectors
Replace if damaged.
Used with protection type Foundry Plus.3HAC044666-001Protection cover for axis-
6 turning disk
Replace if damaged.
Used with protection type Foundry Plus.3HAC044641-012T40 variseal sealing
Replace if damaged.
Used with protection type Foundry Plus.3HAC4836-24Protection plug for lifting
holes
Replace if damaged.
44 Product manual - IRB 1200
3HAC046983-001 Revision: S
© Copyright 2014 - 2021 ABB. All rights reserved.
2 Installation and commissioning
2.2.2 Protection covers
