Wall mounted
Max. load (emergency stop)Endurance load (in operation)Force
±1940 N±1210 NForce xy
0 ±1340 N0 ±900 NForce z
±1650 Nm±700 NmTorque xy
±610 Nm±300 NmTorque z
Suspended
Max. load (emergency stop)Endurance load (in operation)Force
±1620 N±910 NForce xy
+550 ±1610 N+550 ±980 NForce z
±1550 Nm±570 NmTorque xy
±580 Nm±280 NmTorque z
Requirements, foundation
The table shows the requirements for the foundation where the weight of the
installed robot is included:
NoteValueRequirement
Flat foundations give better repeatability of the
resolver calibration compared to original settings
on delivery from ABB.
0.1/500 mmFlatness of foundation
surface
The value for levelness aims at the circumstance
of the anchoring points in the robot base.
In order to compensate for an uneven surface,
the robot can be recalibrated during installation.
If resolver/encoder calibration is changed this
will influence the absolute accuracy.
The limit for the maximum payload on the robot
is reduced if the robot is tilted from 0°.
5ºMaximum tilt
Contact ABB for further information about accept-
able loads.
The value is recommended for optimal perform-
ance.
22 Hz
Note
It may affect the
manipulator life-
time to have a
lower resonance
frequency than
recommended.
Minimum resonance
frequency
Due to foundation stiffness, consider robot mass
including equipment.
i
For information about compensating for founda-
tion flexibility, see the application manual of the
controller software, section Motion Process
Mode.
i
The minimum resonance frequency given should be interpreted as the frequency of the robot
mass/inertia, robot assumed stiff, when a foundation translational/torsional elasticity is added, i.e.,
the stiffness of the pedestal where the robot is mounted. The minimum resonance frequency should
not be interpreted as the resonance frequency of the building, floor etc. For example, if the equivalent
mass of the floor is very high, it will not affect robot movement, even if the frequency is well below
the stated frequency. The robot should be mounted as rigid as possibly to the floor.
Disturbances from other machinery will affect the robot and the tool accuracy. The robot has
resonance frequencies in the region 10 – 20 Hz and disturbances in this region will be amplified,
although somewhat damped by the servo control. This might be a problem, depending on the
requirements from the applications. If this is a problem, the robot needs to be isolated from the
environment.
