NoteArticle numberSpare part
Not used with protection class
IP40.
Replace if damaged.
3HAC056707-001 /
3HAC080701-001
Gasket for tubular cable housing
cover
Includes tubular flange, air con-
nectors and seal bolts.
Replace if damaged.
3HAC049664-001Air connector set with Ethernet
hole in flange
Includes tubular flange, air con-
nectors and seal bolts.
Replace if damaged.
3HAC049665-001Air connector set without Ether-
net hole in flange
Used with protection type Hy-
gienic.
Includes Ethernet connector, air
connectors, CP/CS connector
and gasket (3HAC078804-001).
3HAC079691-001Plate with connector set
Used with protection type Hy-
gienic.
Includes gasket (3HAC078804-
001).
3HAC078810-001Plate without connector set
Used with protection type Hy-
gienic.
Replace if damage.
3HAC078804-001Gasket
Required tools and equipment
NoteArticle numberEquipment, etc.
Used to release the motor brakes.-24 VDC power supply
Content is defined in section Standard
toolkit on page 890.
-Standard toolkit
Required consumables
NoteArt. no.Consumable
Isopropanol-Cleaning agent
-Cable straps
Loctite 7063-Cleaning agent
Loctite 57412340011-116Flange sealing
For robots with protection type
Clean Room.
For robots with food grade lubric-
ation.
Sikaflex 521FC3HAC026759-001Sealant
For robots with protection type
Clean Room.
For robots with food grade lubric-
ation.
Trans Clear3HAC073510-001Sealant
For robots with protection type
Hygienic
Loctite 2433HAB7116-1Locking liquid
Continues on next page
Product manual - IRB 1200 741
3HAC046983-001 Revision: S
© Copyright 2014 - 2021 ABB. All rights reserved.
4 Repair
4.6.6 Replacing the axis-4 timing belt
Continued
