DescriptionRevision
• Added information about o-ring and made other minor improvements
to the instruction for replacing wrist unit, see Replacing wrist unit on
page 262.
• Added information about disconnecting the battery cable when removing
the cable harness, see Removing the complete cable harness on
page 195.
• Corrected the figure that shows location of oil plugs of axis 3 gearbox,
added a funnel to equipment list, see Changing the oil, axis-3 gearbox
on page 167.
• Corrected the figure that shows location of oil plugs of axis 3 gearbox
and adjusted the oil level, see Inspecting the oil level, axis 3 gearbox
on page 127.
• Changed instruction for replacing the wrist unit so that the wrist do not
need to be drained, see Replacing wrist unit on page 262.
• Added Profibus to the section about connections to extra equipment,
see Customer connection on robot on page 108.
• New section added to the manual, see Installation of Foundry Plus Cable
guard (option no. 908-1) on page 100.
• Some general tightening torques have been changed/added, see updated
values in Screw joints on page 437.
• The method of changing the axis-1 gearbox oil in suspended robots is
improved, see the new section Changing the oil, axis-1 gearbox on
suspended robots on page 158.
• Corrected the motor connector pin numbers used for releasing the motor
brakes with external power supply, see Removing motors on page 301
and Refitting motors on page 313.
• Complete process wrist for IRB 2600ID is added to the spare part list
and to the service instructions, see Spare partsand Replacing motor
axis 6 and wrist unit - IRB 2600ID on page 341, also the section Wrist
unit is deleted from the spare part list, since the wrist unit spare part
number already is specified in the upper arm spare part list.
• Added instructions for adjusting the play on motors, see Adjusting the
play on page 352.
• Added Safety risks during handling of batteries on page 38.
The following updates and changes have been made in this revision:D
• Removed faulty information about motors when rebuilding the robot,
see Rebuilding parts.
• Removed faulty information about expansion container for wall mounted
robots, see Changing the oil, axis-1 gearbox on suspended robots on
page 158. Expansion container is not used on wall mounted robots.
• Added ID variants to the information about lower arm when rebuilding
the robot, see Rebuilding parts. Also corrected the ID information in the
spare part list for the lower arm.
• Added correct variant descriptions to the information about IRB 2600ID
upper arms. See Upper arm (IRB 2600ID).
• Mounting angles and values for tilted the variant of the robot added.
• Corrected the spare part numbers for cable harnesses, see Electrical
connections.
• Corrected the spare part number for o-ring pos (5). See Base and frame
unit.
• Spare part number for VK cover, pos 41 was wrong. Has been corrected.
See Upper arm (IRB 2600ID).
• Corrected tightening torque value for oil plugs on axis-1 and axis-2
gearboxes. Correct value is 24 Nm. (Earlier incorrect value: 60 Nm.)
• Information about the type and amount of oil has been removed from
the manual and can now be found in Technical reference manual - Lub-
rication in gearboxes. For article number see References on page 10.
Continues on next page
Product manual - IRB 2600 13
3HAC035504-001 Revision: Q
© Copyright 2009-2018 ABB. All rights reserved.
Overview of this manual
Continued
