Technical data 123
11
Technical data
Contents of this chapter
This chapter contains the technical data for the inverters.
Ratings
The inverter ratings are given below.
Inverter type
PVS800-57-
…
Frame
size
Temp Nominal ratings
I
N(AC)
I
max(DC)
U
N(AC)
P
N(AC)
P
pv
I
sc
PV
Backfeed
current *
Inrush
current
AA VkWkW
p
AAAms
0100kW-A R7i 40 °C 195 245 300 100 120 414 150 400 200
0250kW-A R8i 40 °C 485 600 300 250 300 1035 270 400 200
0315kW-B R8i 45 °C 520 615 350 315 380 1107 270 400 200
0500kW-A 2×R8i 50 °C 965 1145 300 500 600 2061 550 800 200
0630kW-B 2×R8i 45 °C 1040 1230 350 630 760 2214 550 800 200
0875kW-B 3×R8i 50 °C 1445 1710 350 875 1050 3078 440 800 200
1000kW-C 3×R8i 50 °C 1445 1710 400 1000 1200 3078 440 800 200
* The values depend on the fuse ratings.
00592517
I
N(AC)
Continuous AC output current.
P
N(AC)
Continuous AC output power.
I
max(DC)
Maximum input current at nominal output power and ambient temperature
U
N(AC)
Nominal output voltage
P
pv
Recommended maximum input power to ensure full output power at normal radiation
conditions. Inverter limits the power to a safe level.
kW
p
kW peak
I
sc
PV Absolute maximum total photovoltaic array short-circuit current (DC)
Temp Nominal ambient temperature. The values apply to this temperature.
