60 Operation principle and hardware description
Types -0500kW-A to -1000kW-C
Selection Alternatives
Product series PVS800 product series (ABB central inverters)
Type 57 Cabinet-built central inverter. When no options are selected: IP42 (UL
Type 2), AC main contactor, gPV fuses, AC side switch disconnector,
terminals for 230 V AC external control voltage, CDP312 control panel,
RDCO-03 module for optical communication, CE-marked according to
LV and EMC, PVS800 solar inverter control programs, bottom entry and
exit of cables, coated boards, maximum DC voltage 1100 V DC,
ungrounded DC input, IT (ungrounded) AC output, DC input overvoltage
and surge protection (type 1+2), AC output overvoltage protection with
varistors, AC grounding terminals on output busbars, DC input busbars
(number of DC inputs must be selected with a plus code), DC contactor
and main switch, DC grounding terminals on input busbars, grid support
functions (Low voltage ride-through disables anti-islanding functionality,
Reactive power production during the night), a set of manuals, warranty
12/24 months.
Nominal AC power xxxkW Refer to the rating tables, page 123.
Voltage B 350 V AC (operational [MPPT] DC voltage range 525…825 V DC)
C 400 V AC (operational [MPPT] DC voltage range 600…850 V DC)
+ options
Filters E216 EMC/RFI filter for the network side of the transformer on TN (grounded)
low voltage networks
Cabinet and construction
options
C175 Container option for PVS800-IS Must be selected for PVS800-IS
PVS1 and PVS2.
C176 Doors with hinges on the left side
C178 VDE approved
G300 Cabinet heater
G396 Auxiliary power supply, 100 V Only one of options G396, G397,
G398 can be selected. If option
G415 is selected, options G396,
G397, G398 cannot be selected.
G397 Auxiliary power supply, 115 V
G398 Auxiliary power supply, 200 V
G410 Junction box power supply
G415 Auxiliary power supply from main circuit
G416 Current transducers for all DC inputs. Voltage signals to an external
controller.
G417 Current transducers for all DC inputs. Internally monitored and
supervised.
Line options F263 Advanced AC output overvoltage and surge protection
F282 Grounding, positive DC
F283 Grounding, negative DC
0F291 No input DC fuses
Cabling 4H382 4 × fuse-protected DC input connections for 500 kW and 630 kW units
5H382 5 × fuse-protected DC input connections for 500 kW and 630 kW units
8H382 8 × fuse-protected DC input connections for 500 kW, 630 kW, 875 kW
and 1000 kW units
10H382 10 × fuse-protected DC input connections for 500 kW, 630 kW, 875 kW
and 1000 kW units
12H382 12 × fuse-protected DC input connections for 500 kW, 630 kW, 875 kW
and 1000 kW units
15H382 15 × fuse-protected DC input connections for 500 kW, 630 kW, 875 kW
and 1000 kW units
16H382 16 × fuse-protected DC input connections for 875 kW and 1000 kW units
20H382 20 × fuse-protected DC input connections for 875 kW and 1000 kW units
