58 Operation principle and hardware description
Type designation key
The type designation contains information on the specifications and configuration of the
inverter. The first digits from left express the basic configuration, eg, PVS800-57-250kW-A.
The optional selections are given thereafter, separated by plus signs, eg, +Q951. The
main selections are described below. Not all selections are available for all types. For
more information, refer to PVS800-57 ordering information (3AXD10000021367),
available on request.
Types -0100kW-A to -0315kW-B
Selection Alternatives
Product series PVS800 product series (ABB central inverters)
Type 57 Cabinet-built central inverter. When no options are selected: IP42 (UL
Type 2), AC contactor, DC fuses (100 kW), gPV fuses (250 kW and
315 kW), fuse switch, terminals for 230 V AC external control voltage,
CDP312 control panel, RDIO for internal control, RDCO-03 module for
optical communication, EMC filtering, common mode filter, PVS800
solar inverter control programs, bottom entry and exit of cables, coated
boards, maximum DC voltage 1000 V DC, ungrounded DC input, IT
(ungrounded) AC output, DC input overvoltage and surge protection, AC
output overvoltage protection with varistors, AC grounding terminals on
output busbars, DC input busbars (number of DC inputs must be
selected with a plus code), DC contactor and main switch, DC grounding
terminals on input busbars, electrical power network supervision
function, electrical power network support functions, a set of manuals,
warranty 12/24 months.
Nominal AC power xxxkW Refer to the rating tables, page 123.
Voltage A 300 V AC (operational [MPPT] DC voltage range 450…825 V DC)
B 350 V AC (operational [MPPT] DC voltage range 525…825 V DC)
+ options
Filters E216 EMC/RFI filter for the network side of the transformer on TN (grounded)
low voltage networks
Cabinet and construction
options
C178 VDE approved
G300 Cabinet heater
G396 Auxiliary power supply, 100 V, for
250 kW and 315 kW units
Only one of options G396, G397,
G398 can be selected. If option
G415 is selected, options G396,
G397, G398 cannot be selected.
G397 Auxiliary power supply, 115 V, for
250 kW and 315 kW units
G398 Auxiliary power supply, 200 V, for
250 kW and 315 kW units
G410 Junction box power supply
J401 Inverter monitoring display
Line options F263 Advanced AC output overvoltage and surge protection
F282 Grounding, positive DC
F283 Grounding, negative DC
0F291 No input DC fuses
Cabling H377 MCB-protected DC input connections: 4 × miniature circuit breakers for
100 kW units
H382 1 × fuse-protected DC input connections for 100 kW units
2H382 2 × fuse-protected DC input connections for 250 kW and 315 kW units
4H382 4 × fuse-protected DC input connections for 250 kW and 315 kW units
8H382 8 × fuse-protected DC input connections for 250 kW and 315 kW units
