132 Technical data
Dimensions, weights and free space requirements
The heights and depths of the cabinet are given below.
The widths of the cabinet are given below.
The weights of the cabinet are given below.
Inverter type
PVS800-57-…
Height Depth
mm in. mm in.
0100kW-A 2130 83.84 690 27.17
0250kW-A 2130 83.84 680 26.77
0315kW-B 2130 83.84 680 26.77
0500kW-A 2130 83.84 708 27.87
0630kW-B 2130 83.84 708 27.87
0875kW-B 2130 83.84 708 27.87
1000kW-C 2130 83.84 708 27.87
Inverter type
PVS800-57-…
Width (mm)
+H377 +H382
+2H382 +4H382 +5H382 +8H382
+10H382 +12H382 +15H382 +16H382 +20H382
0100kW-A 1030 1030 - - - - - - - - -
0250kW-A - - 1830 1830 - 2230 - - - - -
0315kW-B - - 1830 1830 - 2230 - - - - -
0500kW-A - - - 2630 2630 3030 3030 3430 3430 - -
0630kW-B - - - 2630 2630 3030 3030 3430 3430 - -
0875kW-B - - - - - 3630 3630 4030 4030 4430 4430
1000kW-C - - - - - 3630 3630 4030 4030 4430 4430
Inverter type
PVS800-57-…
Weight (kg)
+H377 +H382
+2H382 +4H382 +5H382 +8H382
+10H382 +12H382 +15H382 +16H382 +20H382
0100kW-A 700 600 - - - - - - - - -
0250kW-A - - 1100 1200 - 1320 - - - - -
0315kW-B - - 1100 1200 - 1320 - - - - -
0500kW-A - - - 1640 1650 1760 1770 1880 1890 - -
0630kW-B - - - 1640 1650 1760 1770 1880 1890 - -
0875kW-B - - - - - 2320 2330 2440 2450 2560 2570
1000kW-C - - - - - 2320 2330 2440 2450 2560 2570
