Ambient conditions
Environmental limits for the inverter are given below. The inverter is to be
used in a heated, indoor, controlled environment.
Note: If the installation has ventilation ducts directly to outdoors (eg, a
container installation), back flow of moist and dusty air must be prevented.
See section Ventilation duct at the air outlet of the cabinet on page 69.
Operation
installed for stationary
use
Storage
in the protective
package
Transportation
in the protective
package
Installation site altitude Types -0100kW-A, -
0250kW-A, 0315kW-B:
0 to 2000 m (6562 ft)
above sea level
Types -0500kW-A,
-0630kW-B, 0875kW-B
and -1000kW-C:
0 to 4000 m (13123 ft)
Above 1000 m (281 ft),
see section Altitude
derating on page 124.
--
Air temperature Types -0100kW-A and
-0250kW-A: -15 to
+55 °C (5 to 131 °F)
Types -0315kW-B,
-0500kW-A, -0630kW-B,
-0875kW-B and
-1000kW-C: -15 to
+60 °C (5 to 140 °F)
If the operating
temperature falls below
0 °C (32 °F), cabinet
heater option +G300 has
to be used.
No frost allowed. See
section Temperature
rating curves.
-40 to +70 °C (-40 to
+158 °F)
-40 to +70 °C (-40 to
+158 °F)
Relative humidity 5 to 95% Max. 95% Max. 95%
No condensation allowed. Maximum allowed relative humidity is 60% in the
presence of corrosive gases.
If the inverter is installed on a site where the relative humidity limits may be
exceeded, cabinet heater option +G300 has to be used.
Environmental category
(IEC 62109-1)
Indoor conditioned
Wet conditions
(IEC 62109-1)
Not to be used in wet location. The installation location must be dry.
Pollution degree
(IEC 62109-1)
2. Normally only non-conductive pollution is allowed.
Contamination levels
(IEC 60721-3-3, IEC 60721-3-
2, IEC 60721-3-1)
No conductive dust allowed.
Chemical gases: Class
3C1
Solid particles: Class
3S2
Chemical gases: Class
1C2
Solid particles: Class
1S3
Chemical gases: Class
2C2
Solid particles: Class
2S2
Atmospheric pressure 61.6 to 106 kPa
0.7 to 1.05 atmospheres
70 to 106 kPa
0.7 to 1.05 atmospheres
60 to 106 kPa
0.6 to 1.05 atmospheres
