Electrical installation 91
Connecting the junction box power supply
(option +G410)
The maximum allowed current that can be connected to the power supply is 6 A.
Connecting the EMC filter (option +E216)
Connect the EMC filter on the network side of the low voltage transformer.
Connecting the control cables
External control cable connections to the RMIO board terminals of the inverter are shown
below. For more information, see the firmware manual.
230 V
N
PVS800-57
1
2
3
X21
F21
Junction box Junction box
L1
L2
L3
PVS800-57
EMC
filter
400 V300 V
