130 Technical data
Fuses for inverters delivered without input DC fuses (option
+0F291)
The table below shows the rated DC current for selecting the input DC fuses (see the next
table) as per the number of the DC input connections to the solar generator.
The table below shows the recommended input DC fuse types. For other fuses, contact
ABB.
No. of DC input
connections
Rated current for the input DC fuses (A)
-0250kW-A -0315kW-B -0500kW-A -0630kW-B -0875kW-A -1000kW-A
2 400 A 400 A - - - -
3 315 A 355 A - - - -
4 250 A 250 A 400 A 400 A - -
5 200 A 200 A 400 A 400 A - -
6 160 A 200 A 355 A 355 A - -
7 160 A 160 A 315 A 315 A - -
8 160 A 160 A 250 A 250 A 400 A 400 A
9 - - 250 A 250 A 355 A 355 A
10 - - 200 A 200 A 315 A 315 A
11 - - 200 A 200 A 315 A 315 A
12 - - 200 A 200 A 250 A 250 A
13 - - 160 A 160 A 250 A 250 A
14 - - 160 A 160 A 250 A 250 A
15 - - 160 A 160 A 200 A 200 A
16 ----200 A200 A
17 ----200 A200 A
18 ----200 A200 A
19 ----160 A160 A
20 ----160 A160 A
Rated DC fuse
current of the
inverter
(A)
Recommended input DC fuses
400 A PV-400AF3
355 A PV-355AF3
315 A PV-315AF3
250 A PV-250AF2
200 A PV-200AF2
160 A PV-160AF2
