128 Technical data
 Inverter DC fuses
 DC fuses for 2 DC input connections (option +2H382)
 DC fuses for 4 DC input connections (option +4H382)
 DC fuses for 5 DC input connections (option +5H382)
 DC fuses for 8 DC input connections (option +8H382)
Inverter type Fuse information
Qty Rated current
(A)
Bussmann Mersen
PVS800-57-0100kW-A 2 400 170M6303 -
PVS800-57-0250kW-A 2 800 170M5398 11URD73PA0800
PVS800-57-0315kW-B 2 800 170M5398 11URD73PA0800
PVS800-57-0500kW-A 4 800 170M5398 11URD73PA0800
PVS800-57-0630kW-B 4 800 170M5398 11URD73PA0800
PVS800-57-0875kW-B 6 800 170M5398 11URD73PA0800
PVS800-57-1000kW-C 6 800 170M5398 11URD73PA0800
Inverter type Fuse information
Qty Rated current
(A)
Bussmann
PVS800-57-0250kW-A 4 400 PV-400AF3
PVS800-57-0315kW-B 4 400 PV-400AF3
Inverter type Fuse information
Qty Rated current
(A)
Bussmann
PVS800-57-0250kW-A 8 250 PV-250AF2
PVS800-57-0315kW-B 8 315 PV-315AF3
PVS800-57-0500kW-A 8 400 PV-400AF3
PVS800-57-0630kW-B 8 400 PV-400AF3
Inverter type Fuse information
Qty Rated current
(A)
Bussmann
PVS800-57-0500kW-A 10 400 PV-400AF3
PVS800-57-0630kW-B 10 400 PV-400AF3
Inverter type Fuse information
Qty Rated current
(A)
Bussmann
PVS800-57-0250kW-A 16 160 PV-160AF2
PVS800-57-0315kW-B 16 160 PV-160AF2
PVS800-57-0500kW-A 16 250 PV-250AF2
PVS800-57-0630kW-B 16 250 PV-250AF2
PVS800-57-0875kW-B 16 400 PV-400AF3
PVS800-57-1000kW-C 16 400 PV-400AF3
