66 Mechanical installation
Placing the unit
Move the cabinet into its final position with an iron bar and a piece of wood at the bottom
edge of the cabinet. Place the wooden piece properly in order not to damage the cabinet
frame!
Overview of the installation process
The unit must be installed in an upright vertical position. It can be installed with its back
against a wall, or back-to-back with another unit and side by side. Fasten the cabinet to
the floor (and roof) as described under Fastening the cabinet to the floor, page 67.
Note 1: Leave required free space around the unit. See page 132.
Note 2: Height adjustment can be done by using metal shims between the bottom frame
and floor.
