Technical data 127
Type equivalence table
Fuses
Data for the factory-installed fuses are given in the tables below. Fuses from other
manufacturers can be used if they meet the given ratings.
 Main circuit AC fuses
Inverter type Frame
size
Inverter module(s) used LCL filter(s) used
PVS800-57-0100kW-A R7i PVS800-104-0105kW-A SLCL-05
PVS800-57-0250kW-A R8i PVS800-104-0250kW-A SLCL-16
PVS800-57-0315kW-B R8i PVS800-104-0315kW-B SLCL-16
PVS800-57-0500kW-A 2×R8i 2×PVS800-104-0250kW-A 2×SLCL-16
PVS800-57-0630kW-B 2×R8i 2×PVS800-104-0315kW-B 2×SLCL-16
PVS800-57-0875kW-B 3×R8i 3xPVS800-104-0315kW-B 3xSLCL-17
PVS800-57-1000kW-C 3×R8i 3xPVS800-104-0315kW-B 3xSLCL-17
Inverter type Fuse information
Qty Rated current
(A)
Bussmann Mersen
PVS800-57-0100kW-A 3 400 170M5808D -
PVS800-57-0250kW-A 3 1000 170M6814D 6,9URD3PV1000
PVS800-57-0315kW-B 3 1000 170M6814D 6,9URD3PV1000
PVS800-57-0500kW-A 6 1000 170M6414 6,9URD33TTF1000
PVS800-57-0630kW-B 6 1000 170M6414 6,9URD33TTF1000
PVS875-57-0875kW-B 9 1000 170M6414 6,9URD33TTF1000
PVS800-57-1000kW-C 9 1000 170M6414 6,9URD33TTF1000
