Safety instructions 17
• When removing a module which is equipped with wheels, pull the module carefully
out of the cubicle along the ramp. Make sure the wires do not catch. While pulling
on the handle, keep a constant pressure with one foot on the base of the module
to prevent the module from tipping over. Use safety shoes with metal toe cap to
avoid foot injury.
• When replacing a module which is equipped with wheels, push the module up the
ramp into the cubicle. Keep your fingers away from the edge of the module front
plate to avoid pinching them between the module and the cubicle. Also keep a
constant pressure with one foot on the base of the module to stabilize the
movement.
• Do not use the ramp with plinth heights over 50 mm.The ramp supplied with the
inverter is designed for a plinth height of 50 mm (the standard plinth height of ABB
cabinets). Tighten the four fastening bolts of the ramp carefully.
