ABB PVS800-57-0100kW-A User Manual

Operation principle and hardware description 51
Item Explanation
1 DC (input) connections
2 AC output busbars. They match the quick connector socket mounted in the cubicle.
3 Fiber optic connectors of the AINT board. Connected to the RDCU control unit.
4 Retractable support legs
5 Handle
6 Cooling fan
2
4
3
4
1
5
6
