ABB RET670 Applications Manual

1.1.3 Intended audience
General
The application manual is addressing the system engineer/technical responsible that is
responsible for specifying the application of the IED.
Requirements
The system engineer/technical responsible must have a good knowledge about
protection systems, protection equipment, protection functions and the configured
functional logics in the protection.
1.1.4 Related documents
Documents related to RET670 Identity number
Operator’s manual 1MRK 504 114-UUS
Installation and commissioning manual 1MRK 504 115-UUS
Technical reference manual 1MRK 504 113-UUS
Application manual 1MRK 504 116-UUS
Product guide customized 1MRK 504 117-BUS
Product guide pre-configured 1MRK 504 118-BUS
Sample specification SA2005-001283
Connection and Installation components 1MRK 513 003-BEN
Test system, COMBITEST 1MRK 512 001-BEN
Accessories for 670 series IEDs 1MRK 514 012-BEN
670 series SPA and signal list 1MRK 500 092-WUS
IEC 61850 Data objects list for 670 series 1MRK 500 091-WUS
Engineering manual 670 series 1MRK 511 240-UUS
Communication set-up for Relion 670 series 1MRK 505 260-UEN
More information can be found on www.abb.com/substationautomation.
1.1.5 Revision notes
Revision
Description
A Minor corrections made
B Maintenance updates, PR corrections
C Maintenance updates, PR corrections
1MRK504116-UUS C Section 1
Introduction
17
Application manual

ABB RET670 Specifications

General

Rated Frequency	50/60 Hz
Inputs	Analog and binary inputs
Application	Protection of power systems
Communication Protocols	IEC 61850, DNP3, Modbus
Operating Temperature Range	-25°C to +55°C
Mounting	Rack mounted
Number of Binary Inputs	Up to 48
Number of Binary Outputs	32
Protection Functions	Overcurrent Protection
Outputs	Binary outputs
Enclosure	IP 54
Type	Line Differential Protection
Number of Analog Inputs	24
