3.14.6.2 Setting guidelines
The function does not have any parameters available in the local HMI or Protection
and Control IED Manager (PCM600).
3.14.7 Integer to Boolean 16 conversion IB16
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Integer to boolean 16 conversion IB16 - -
3.14.7.1 Application
Integer to boolean 16 conversion function (IB16) is used to transform an integer into a
set of 16 binary (logical) signals. It can be used – for example, to connect integer
output signals from one function to binary (logical) inputs to another function. IB16
function does not have a logical node mapping.
3.14.7.2 Setting parameters
The function does not have any parameters available in the local HMI or Protection
and Control IED Manager (PCM600).
3.14.8 Integer to Boolean 16 conversion with logic node
representation IB16FCVB
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Integer to boolean 16 conversion with
logic node representation
IB16FCVB - -
3.14.8.1 Application
Integer to boolean 16 conversion with logic node representation function (IB16FCVB)
is used to transform an integer into a set of 16 binary (logical) signals. IB16FCVB
function can receive an integer from a station computer – for example, over IEC 61850–
8–1. These functions are very useful when the user wants to generate logical
commands (for selector switches or voltage controllers) by inputting an integer
number. IB16FCVB function has a logical node mapping in IEC 61850.
1MRK504116-UUS C Section 3
IED application
747
Application manual
