3.13.2.3 Setting parameters
Table 200: ECRWPSCH (85) Group settings (basic)
Name Values (Range) Unit Step Default Description
CurrRev Disabled
Enabled
- - Disabled Operating mode of Current Reversal Logic
tPickUpRev 0.000 - 60.000 s 0.001 0.020 Pickup time for current reversal logic
tDelayRev 0.000 - 60.000 s 0.001 0.060 Time Delay to prevent Carrier send and local
trip
WEI Disabled
Echo
Echo & Trip
- - Disabled Operating mode of WEI logic
tPickUpWEI 0.000 - 60.000 s 0.001 0.000 Coordination time for the WEI logic
VBase 0.05 - 2000.00 kV 0.05 400.00 Base setting for voltage level
3V0PU 5 - 70 %VB 1 25 Neutral voltage setting for fault conditions
measurement
3.14 Logic
3.14.1 Tripping logic SMPPTRC (94)
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Tripping logic SMPPTRC
I->O
SYMBOL-K V1 EN
94
3.14.1.1 Application
All trip signals from the different protection functions shall be routed through the trip
logic. In its simplest alternative the logic will only link the TRIP signal and make sure
that it is long enough.
Tripping logic SMPPTRC (94) offers three different operating modes:
• Three-pole tripping for all fault types (3ph operating mode)
• Single-pole tripping for single-phase faults and three-pole tripping for multi-phase
and evolving faults (1ph/3ph operating mode). The logic also issues a three-pole
