SIRLevel: The setting of the parameter SIRLevel is by default set to 10. This is a
suitable setting for applications with CVT to avoid transient overreach due to the CVT
dynamics. If magnetic voltage transformers are used, set SIRLevel to 15 the highest level.
IMinOp: The minimum operate current for the SIR measurement is by default set to
20% of IBase.
3.6.7.3 Setting parameters
Table 68: ZSMGAPC Group settings (basic)
Name Values (Range) Unit Step Default Description
IBase 1 - 99999 A 1 3000 Base value for current measurement
VBase 0.05 - 2000.00 kV 0.05 400.00 Base value for voltage measurement
PilotMode Disabled
Enabled
- - Disabled Pilot mode Disable / Enable
Zreach 0.1 - 3000.0 ohm 0.1 38.0 Line impedance
IMinOp 10 - 30 %IB 1 20 Minimum operating current for SIR
measurement
Table 69: ZSMGAPC Group settings (advanced)
Name
Values (Range) Unit Step Default Description
DeltaI 0 - 200 %IB 1 10 Current change level in %IB for fault inception
detection
Delta3I0 0 - 200 %IB 1 10 Zero seq current change level in % of IB
DeltaV 0 - 100 %VB 1 5 Voltage change level in %VB for fault
inception detection
Delta3V0 0 - 100 %VB 1 5 Zero seq voltage change level in % of VB
SIRLevel 5 - 15 - 1 10 Settable level for source impedance ratio
3.6.8 Faulty phase identification with load encroachment
FMPSPDIS (21)
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Faulty phase identification with load
encroachment for mho
FMPSPDIS
S00346 V1 EN
21
