3.6.13.3 Setting parameters
Table 81: PSPPPAM (78) Group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Disabled
Enabled
- - Disabled Operation Enable / Disable
OperationZ1 Disabled
Enabled
- - Enabled Operation Enable/Disable zone Z1
OperationZ2 Disabled
Enabled
- - Enabled Operation Enable/Disable zone Z2
ImpedanceZA 0.00 - 1000.00 % 0.01 10.00 Forward impedance in % of Zbase
ImpedanceZB 0.00 - 1000.00 % 0.01 10.00 Reverse impedance in % of Zbase
ImpedanceZC 0.00 - 1000.00 % 0.01 10.00 Impedance of zone1 limit in % of Zbase
AnglePhi 72.00 - 90.00 Deg 0.01 85.00 Angle of the slip impedance line
StartAngle 0.0 - 180.0 Deg 0.1 110.0 Rotor angle for the pickup signal
TripAngle 0.0 - 180.0 Deg 0.1 90.0 Rotor angle for the trip1 and trip2 signals
N1Limit 1 - 20 - 1 1 Count limit for the trip1 signal
N2Limit 1 - 20 - 1 3 Count limit for the trip2 signal
Table 82: PSPPPAM (78) Group settings (advanced)
Name
Values (Range) Unit Step Default Description
ResetTime 0.000 - 60.000 s 0.001 5.000 Time without slip to reset all signals
Table 83: PSPPPAM (78) Non group settings (basic)
Name
Values (Range) Unit Step Default Description
IBase 0.1 - 99999.9 A 0.1 3000.0 Base Current (primary phase current in
Amperes)
Vbase 0.1 - 9999.9 kV 0.1 20.0 Base Voltage (primary phase-to-phase
voltage in kV)
MeasureMode PosSeq
AB
BC
CA
- - PosSeq Measuring mode (PosSeq, AB, BC, CA)
InvertCTcurr No
Yes
- - No Invert current direction
3.6.14 Phase preference logic PPLPHIZ
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Phase preference logic PPLPHIZ - -
