Table 205: PULSETIMER Non group settings (basic)
Name Values (Range) Unit Step Default Description
T 0.000 - 90000.000 s 0.001 0.010 Time delay of function
Table 206: SRMEMORY Group settings (basic)
Name Values (Range) Unit Step Default Description
Memory Disabled
Enabled
- - Enabled Operating mode of the memory function
Table 207: RSMEMORY Group settings (basic)
Name Values (Range) Unit Step Default Description
Memory Disabled
Enabled
- - Enabled Operating mode of the memory function
Table 208: GATE Group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Disabled
Enabled
- - Disabled Operation Disabled/Enabled
Table 209: TIMERSET Group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Disabled
Enabled
- - Disabled Operation Disabled/Enabled
t 0.000 - 90000.000 s 0.001 0.000 Delay for settable timer n
3.14.4 Fixed signal function block FXDSIGN
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Fixed signals FXDSIGN - -
3.14.4.1 Application
The Fixed signals function (FXDSIGN) generates a number of pre-set (fixed) signals
that can be used in the configuration of an IED, either for forcing the unused inputs in
other function blocks to a certain level/value, or for creating certain logic.
