3.14.1.3 Setting parameters
Table 201: SMPPTRC (94) Group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Disabled
Enabled
- - Enabled Disable/Enable Operation
Program 3 phase
1p/3p
1p/2p/3p
- - 1p/3p Three pole; single or three pole; single, two or
three pole trip
tTripMin 0.000 - 60.000 s 0.001 0.150 Minimum duration of trip output signal
tWaitForPHS 0.020 - 0.500 s 0.001 0.050 Secures 3-pole trip when phase selection
failed
Table 202: SMPPTRC (94) Group settings (advanced)
Name Values (Range) Unit Step Default Description
TripLockout Disabled
Enabled
- - Disabled If TripLockout is set to On, it will activate
output (CLLKOUT) and trip latch. If set to Off
it will activate only CLLKOUT
AutoLock Disabled
Enabled
- - Disabled If AutoLock is set to On i will activate lockout
from input (SETLKOUT) and trip, If set to Off
it will activate only from SETLKOUT
3.14.2 Trip matrix logic TMAGGIO
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Trip matrix logic TMAGGIO - -
3.14.2.1 Application
Trip matrix logic TMAGGIO function is used to route trip signals and other logical
output signals to different output contacts on the IED.
TMAGGIO output signals and the physical outputs allows the user to adapt the signals
to the physical tripping outputs according to the specific application needs.
3.14.2.2 Setting guidelines
Operation: Operation of function Enabled/Disabled.
