ABB RET670 Applications Manual

Name Values (Range) Unit Step Default Description
CodeType BIN
BCD
Gray
SINGLE
mA
- - BIN Type of code conversion
UseParity Disabled
Enabled
- - Disabled Enable parity check
tStable 1 - 60 s 1 2 Time after position change before the value is
accepted
CLFactor 1.0 - 3.0 - 0.1 2.0 Adjustable factor for contact life function
InitCLCounter 0 - 9999999 s 1 250000 CL counter start value
EnabTapCmd Disabled
Enabled
- - Enabled Enable commands to tap changer
Table 171: TCLYLTC (84) Group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Disabled
Enabled
- - Disabled Operation Disable / Enable
IBase 1 - 99999 A 1 3000 Base current in primary Ampere for the HV-
side
tTCTimeout 1 - 120 s 1 5 Tap changer constant time-out
tPulseDur 0.5 - 10.0 s 0.1 1.5 Raise/lower command output pulse duration
Table 172: TCLYLTC (84) Non group settings (basic)
Name
Values (Range) Unit Step Default Description
LowVoltTap 1 - 63 - 1 1 Tap position for lowest voltage
HighVoltTap 1 - 63 - 1 33 Tap position for highest voltage
mALow 0.000 - 25.000 mA 0.001 4.000 mA for lowest voltage tap position
mAHigh 0.000 - 25.000 mA 0.001 20.000 mA for highest voltage tap position
CodeType BIN
BCD
Gray
SINGLE
mA
- - BIN Type of code conversion
UseParity Disabled
Enabled
- - Disabled Enable parity check
tStable 1 - 60 s 1 2 Time after position change before the value is
accepted
CLFactor 1.0 - 3.0 - 0.1 2.0 Adjustable factor for contact life function
InitCLCounter 0 - 9999999 s 1 250000 CL counter start value
EnabTapCmd Disabled
Enabled
- - Enabled Enable commands to tap changer
1MRK504116-UUS C Section 3
IED application
705
Application manual

ABB RET670 Specifications
