Abbott VP 2000 - Page 116

Maintenance and Diagnostic Procedures Section 5
5-26 Abbott VP 2000™ Processor Service Manual
30-608308/R1—September 2008
6. Select the <Basin> tab and from the dropdown menu,
select <Dryer Station>.
Figure 5.9: Select Drying Station from Basin Dropdown
7. In the <Time (m:s)> tab enter 10:00.
Figure 5.10: Enter Time
8. In the <Temp (
o
C)> tab enter 80.
Figure 5.11: Enter Temperature
Dryer Test
Dryer Test
Drying Station
...
...
10:00
Dryer Test
Drying Station
...
...
10:00
80
