Section 5 Drying Station Temperature Check
Abbott VP 2000™ Processor Service Manual 5-27
30-608308/R1—September 2008
9. Select the <Save As> tab, and enter “Dryer Test.”
Figure 5.12: Save As <Dryer Test>
10. Select <Save> to save the file.
11. Place ten (10) clean slides in the Slide Basket, evenly
spaced over the length of the Slide Basket (first slide on the
inboard side of the Slide Basket next to the Robotic Arm
attachment lugs) with four (4) empty spaces between each
slide.
Figure 5.13: Clean Slides in Slide Basket
Dryer Test
First Slide
