Section 6 Maintenance Diagnostic Faults
Abbott VP 2000™ Processor Service Manual 6-47
30-608308/R1—September 2008
Figure 6.19: No Heat in Dryer
NO HEAT IN DRYER
CHECK DRYER CONNECTIONS AT
HARNESS SHROUD
REALIGN & PLUG IN
PASS FAIL
CHECK DRYER ELEMENT
PASS FAIL
REPLACE DRYER
ELEMENT ASSEMBLY
CHECK VOLTAGE
FAIL
POWER SUPPLY BOARD
TEST BY SUBSTITUTION
2
3
1
PASS
REPLACE POWER SUPPLY BOARD
TEST TEMPERATURE SENSOR
PASS
4
FAIL
REPLACE DRYER ASSEMBLY
CHECK/ADJUST TEMPERATURE
CALIBRATION
PASS FAIL
5
COMPUTER BOARD
TEST BY SUBSTITUTION
TEST CONTROL MODULE
TEST BY SUBSTITUTION
6
6
6
RECALIBRATE
