CIEDGE (Comparator Interrupt Flag Edge Register) : ADH
7
6
5
4
3
2
1
0
-
-
-
CIEDGE4
CIEDGE3
CIEDGE2
CIEDGE1
CIEDGE0
-
-
-
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
CIEDGE4
Determines the type of Comparator4 interrupt, edge or level sensitive.
0
Level (default)
1
Edge
CIEDGE3
Determines the type of Comparator3 interrupt, edge or level sensitive.
0
Level (default)
1
Edge
CIEDGE2
Determines the type of Comparator2 interrupt, edge or level sensitive.
0
Level (default)
1
Edge
CIEDGE1
Determines the type of Comparator1 interrupt, edge or level sensitive.
0
Level (default)
1
Edge
CIEDGE0
Determines the type of Comparator0 interrupt, edge or level sensitive.
0
Level (default)
1
Edge
CIPOLA (Comparator Interrupt Flag Polarity Register) : AEH
7
6
5
4
3
2
1
0
-
-
-
CIPOLA4
CIPOLA3
CIPOLA2
CIPOLA1
CIPOLA0
-
-
-
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
According to CIEDGE, this register acts differently. If CIEDGE is level
type, comparator interrupt polarity have level value. If CIEDGE is edge
type, comparator interrupt polarity have edge value.
CIPOLA4
Determine the polarity of Comparator4 Interrupt
0
When High level or rising edge, Interrupt occurs(default)
1
When Low level or falling edge, Interrupt occurs
CIPOLA3
Determine the polarity of Comparator3 Interrupt
0
When High level or rising edge, Interrupt occurs(default)
1
When Low level or falling edge, Interrupt occurs
CIPOLA2
Determine the polarity of Comparator2 Interrupt
0
When High level or rising edge, Interrupt occurs(default)
1
When Low level or falling edge, Interrupt occurs
CIPOLA1
Determine the polarity of Comparator1 Interrupt
0
When High level or rising edge, Interrupt occurs(default)
1
When Low level or falling edge, Interrupt occurs
CIPOLA0
Determine the polarity of Comparator0 Interrupt
0
When High level or rising edge, Interrupt occurs(default)
1
When Low level or falling edge, Interrupt occurs
