MC97F6108A User’s manual 6. Interrupt controller
71
CIBOTH (Comparator Interrupt Flag Both Edge Enable Register) : AFH
7
6
5
4
3
2
1
0
-
-
-
CIBOTH4
CIBOTH3
CIBOTH 2
CIBOTH 1
CIBOTH 0
-
-
-
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
If CIBOTHx is written to ‘1’, the corresponding comparator interrupt is
enabled by both edges(no level).
And CIEDGE and CIPOLA register value are ignored.
CIBOTH4
Determine the type of Comparator4 Interrupt
0
Both edge detection Disable (default)
1
Both edge detection Enable
CIBOTH3
Determine the type of Comparator3 Interrupt
0
Both edge detection Disable (default)
1
Both edge detection Enable
CIBOTH2
Determine the type of Comparator2 Interrupt
0
Both edge detection Disable (default)
1
Both edge detection Enable
CIBOTH1
Determine the type of Comparator1 Interrupt
0
Both edge detection Disable (default)
1
Both edge detection Enable
CIBOTH0
Determine the type of Comparator0 Interrupt
0
Both edge detection Disable (default)
1
Both edge detection Enable
CFENAB (Comparator Flag Enable Register) : D8H
7
6
5
4
3
2
1
0
-
-
-
CFENAB4
CFENAB3
CFENAB2
CFENAB1
CFENAB0
-
-
-
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
CFENAB4
Enable or Disable Comparator4 Flag generation
0
Disable Comparator4 Flag generation(default)
1
Enable Comparator4 Flag generation
CFENAB3
Enable or Disable Comparator3 Flag generation
0
Disable Comparator3 Flag generation(default)
1
Enable Comparator3 Flag generation
CFENAB2
Enable or Disable Comparator2 Flag generation
0
Disable Comparator2 Flag generation (default)
1
Enable Comparator2 Flag generation
CFENAB1
Enable or Disable Comparator1 Flag generation
0
Disable Comparator1 Flag generation (default)
1
Enable Comparator1 Flag generation
CFENAB0
Enable or Disable Comparator0 Flag generation
0
Disable Comparator0 Flag generation (default)
1
Enable Comparator0 Flag generation
