Accu-Chek Mobile User Manual

150
Using the meter as a diary5
2 Use to select All results, Before meal or
After meal.
3 Press
(Select).
4 Use
to choose the period in which the
results were obtained: 7, 14 or 30 days.
Selecting the time period only determines which aver-
age will be displayed rst. You can later switch directly
from one time period to the others.
5 Press
(Select).
The selected average is displayed, together with the
number of results (called tests) from which the average
was calculated.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
