Accu-Chek Mobile User Manual

26
Getting to know your meter and lancing device1
button (On/Off button / Enter button)
This button allows you
to turn the meter on or off (

press and hold the
button, see Chapter 1.6 and 1.7); as On/Off button,
this button is indicated in the User’s Manual by the
symbol
,
or
to execute the command displayed above the button

(press and release the button); as Enter button to
execute the command displayed, the button is indi-
cated by the symbol
.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
