Accu-Chek Mobile User Manual

76
Testing blood glucose3
Turning off the meter
Turning off via the tip cover
Close the tip cover.
The meter displays the number of available tests and
then turns off.
i
The result will be displayed for at least
15 seconds. If you close the tip cover before the
end of this time, the result will continue to be
displayed. The number of available tests does
not appear until the 15 seconds have elapsed.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
