Accu-Chek Mobile User Manual

20
Getting to know your meter and lancing device1
1.4 The main features at a glance
Test cassette instead of test strips

The test cassette contains a continuous tape on
which there are 50 test areas. When a test is to be
performed a test area is automatically advanced to
the tip of the cassette.
Easy testing

For testing, you do not need to press a single button.
You open the tip cover, apply blood to the test area,
read the result and close the tip cover.
Docked lancing device

You can obtain blood with the lancing device still
docked onto the meter. Or you can undock the
lancing device and then use it to obtain blood.
Lancing device with lancet supply

A drum containing 6 sterile lancets is placed in the
lancing device. Pushing the lever on the lancing
device rotates the drum to the next lancet. This
means that you can obtain blood with a new and
sterile lancet 6 times before you have to replace the
drum.
No coding

Each test cassette contains an RFID (radio frequency
identication) chip. This automatically codes the
meter when you insert a test cassette and informs
the meter about the specic properties of the test
areas in this test cassette.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
