Accu-Chek Mobile User Manual

61
Testing blood glucose 3
Replacing a used lancet drum
When you have used the sixth and last lancet, you
need to replace the used lancet drum with a new one.
1 Remove the cap from the lancing device.
2 Grasp the lancet drum at the cut-outs on the
lancing device.
3 Pull the lancet drum out of the lancing device.
Used lancet drums can be disposed of in household
waste.
4 Insert a new lancet drum (see section “Inserting a
lancet drum”).

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
