Accu-Chek Mobile User Manual

57
Testing blood glucose 3
Inserting a lancet drum
new lancet drum used lancet drum
red line
To use the lancing device to obtain blood, you must
rst insert a lancet drum.
1 Take a new lancet drum.
You can tell that a lancet drum has been used because
it has a red line visible on the white portion. You cannot
insert a used lancet drum again.
2 Remove the cap from the lancing device.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
