Testing blood glucose3
You do not need to load a new lancet if you just in-
serted a new lancet drum.
Loading a new lancet
If you have already used the lancing device to obtain
blood, you will need a new lancet the next time you
obtain blood. For this, the lancet drum must be rotated
in the lancing device.
Push the lever at the side of the lancing device to the
right as far as it will go (1) and then back to the left (2).
The lancet drum rotates a little further and the next
lancet will be advanced to the correct position and is
now ready for use.
The window on the side of the lancing device now
shows one less available lancet, e.g. 5 instead of
previously 6. When you have loaded the sixth and last
lancet, the window shows 1.
If 1 appears in the window, the lever will be
blocked by a locking mechanism. Do not force
the lever beyond this locking mechanism as this
will damage the lancing device.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
