Accu-Chek Mobile User Manual

38
Getting to know your meter and lancing device1
Activating or deactivating functions
Some functions, e.g. the beeper and agging results
can only be activated or deactivated.
You can recognize these functions by the fact that
there is either a checkmark
or a checkbox in
front of them and the command above the
but-
ton is Off or On (if there is a different command this
means that the function can also be modied).
A checkmark means that the function is activated.
The command for the
button is Off to allow you
to deactivate the function.
Press the
button (Off) to deactivate the activated
function.
A checkbox means that the function is deactivated.
The command for the
button is On to allow you
to activate the function.
Press the
button (On) to activate a deactivated
function.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
