Accu-Chek Mobile User Manual

62
Testing blood glucose3
Undocking and docking the lancing device
If you wish to use the lancing device separately from
the meter, detach it as follows:
1 Push the release button for the lancing device (on
the back of the meter) in the direction of the arrow
as far as it will go. Hold it in this position until you
have undocked the lancing device.
2 Withdraw the lancing device by sliding it out in the
direction of the arrow.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
