63
Testing blood glucose 3
To dock the lancing device on to the meter again,
proceed as follows:
There are 2 guide tracks on the meter and the lancing
device, respectively. When docking the lancing device,
the tracks on the lancing device must t into the tracks
in the recess at the side of the meter.
1 Position the lancing device at the lower end of the
recess with the multifunction button at the top and
the writing “Accu-Chek FastClix Mobile” facing the
meter.
2 Slide the lancing device along the side of the
meter in the direction of the arrow until it slots into
place with an audible CLICK.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
