Getting to know your meter and lancing device1
Elements of the menus
The following illustrations show the main elements that
can appear in a menu.
1
Title of the display or menu (not in all displays).
2
Selected item, highlighted with a yellow bar. If you
press the
button, this item will be selected
(command “Select” above the button). This will
take you to a higher- or lower-level menu, for
example, or open the display for entering a number.
3
Unselected item.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
