Accu-Chek Mobile User Manual

77
Testing blood glucose 3
Turning off using the On/Off button
1 Press and hold the On/Off button until the
bar on the display is lled (at least 2 seconds).
Before the meter turns off, it prompts you to close the
tip cover and then display the number of available tests
for your information.
2 Close the tip cover.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
