Accu-Chek Mobile User Manual

162
Using the meter as a diary5
5–20 cm
1 Turn on the computer.
2 Position the meter 5–20 cm away from the infrared
window of the computer. Point the two infrared
windows towards one another.
3 In the Transfer data menu: Use to select
Table to PC.
4 Press the
(Select) to start transferring the
results.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
