Accu-Chek Mobile User Manual

199
Cleaning the meter and lancing device 11
11 Carefully wipe the interior of the tip cover with a
lightly moistened cloth or cotton swab.
Make sure that no liquid enters the meter. Avoid
scratching the measuring optics. Scratches
could interfere with tests.
12 Remove any uff or lint that may remain.
13 Allow the meter time to dry thoroughly.

Accu-Chek Mobile Specifications

General

Measurement Technology	Photometric
Sample Type	Capillary whole blood
Sample Size	0.3 µL
Test Time	5 seconds
Battery Type	2 AAA batteries
Connectivity	USB
Dimensions	121 x 63 x 20 mm
Weight	129 g (with batteries)
Display	LCD
Memory Capacity	2000 results
Measuring Range	0.6 - 33.3 mmol/L
Operating Temperature	10 - 40°C
Operating Humidity	10 to 90% RH
Hematocrit Range	20 to 70%
Test Strip Technology	No test strips required (uses a test cassette)
