ACO 6236 - AC Adaptor

13
Example of system configuration
※ The function can be extended by the connecting various option measuring instruments.
AC adaptor
1) Turn off the power switch.
2) Connect the AC adaptor to the AC adaptor terminal.
3) Insert the AC plug of the AC adaptor to the AC100V outlet.
NOTE
Please do not use any other power supplies than
specified AC
adaptor. It may cause breakdown or malfunction.
AC adaptor
AC power adaptor
connector
to AC100V outlet
Windscreen（φ50）
NA-0304
Sound Calibrator
TYPE 2127
Extension cable for microphone
BC-0046-2～
Tripod exclusively
for sound level meter
NA-0333
Level recorder
TYPE5008A
Program cards（SD card）
1/1and 1/3-octave Real-time Analysis Card
NA-0038
NA-0038F
NA-0038R
FFT Analysis Card
Real Sound Monitor Card
Oscilloscope
BNC pin cord
BC-0071
Sound Level Meter
TYPE6236
AC adapter
AC-1026
WT-51E
220～240V-100V
Conversion
Transformer
PC
Data measurement software
NA-0038X
BC-0038PC
USB interface cable
Memory Card (SD Card)
BC-0026PC
Interface cable
