7. Remote Control Operation
7.1 Connection with the TYPE 6236
Set TYPE 6236 to communication mode (Remote) and connect TYPE 6236 with PC using USB
interface cable included in the software as shown below.
Connection procedure is as follows.
1. Turn on the power of the TYPE 6236.
2. Set TYPE 6236 to communication mode (Remote).
At the [Menu] <System> 1/3 screen, change the [Mode : Normal] to
[Mode : Remote] using ▲▼ keys. Register the setup by pressing the [Set] key and the
screen will return to measurement screen.
Name of the optional card inserted
at the time will blink.
3. Connect TYPE 6236 and PC using the USB Interface Cable included in the Data
Management Software. USB Interface Cable shall be connected only after the power of
the TYPE 6236 is turned on.
4. Select remote control using the [File management / remote control] button to display
Remote Control Panel. By clicking the [Card] button, set the card type display on the
remote control panel to the same card type recognized by the TYPE 6236. If the card is not
inserted yet, set card type to 【STD】.
<System> 1/3
Mode ：Remote
Data delete ：off
LCD cont ：＊＊＊
Date y/m/d ：01/01/01
Time h/m/s ：00:00:00
Printer(pc)set ：9600
USB out ：OFF
Rec A Fast
Lp
１０ｍ ０００ｈ００ｍ０0ｓ
TYPE 6236
PC
(Data Management Software)
USB Interface Cable
BC-0038PC
To Next Page
