Actia SmarTach - Combination of Pictograms Defined by Annex 1 B

Copyright
©
2005 ACTIA - Appendices - 91
English
Equipment
1 Driver slot
2 Co-driver slot
© Card
ª Clock
« Display
® Printer/Printout
° Vehicle/Vehicle unit
Specific Conditions
OUT Out of Scope
¹ Ferry/Train crossing
Miscellaneous
º Start of daily work period
» End of daily work period
± Location
² Security
ª Time
24h Daily
½ Weekly
´ Two weeks
μ From or to
Cards
¢© Driver card
© Company card
©---No card
6.10.2 Combination of Pictograms Defined by Annex 1B
Driving
¢¢ Crew driving
¢ ½ Driving time for one week
¢´ Driving time for two weeks
Events
!© Insertion of a non-valid card
!©© Card conflict
!ªª Time overlap
!¢© Driving without an appropriate card
!©¢ Card insertion while driving
!©° Last card session not correctly closed
>> Over-speeding
!− Power supply interruption
!¯ Motion data error
!² Security breach
!ª Time adjustment (by workshop)
>¡ Over-speeding control
Faults
·©1 Card fault (driver slot)
·©2 Card fault (co-driver slot)
·« Display fault
·¬ Downloading fault
·® Printer fault
·¯ Sensor fault
·° SmarTach
®
internal fault
