Chapter 5 - Module System Descriptions
102 Adept Python Modules User’s Guide, Rev. E
Figure 5-46. Gantry Over-Travel Specifications
Module aligned
against internal
hardstop
Allow 4 mm - 45 mm of
over-travel in the gantry
module when the primary
module is aligned against its
hardstop, as shown.
Modules at hardstop positions
X
LG6 Gantry Support Module
